Model | HFCG-190FD HFCG-190FD-E | HFCD-188FD | HFCD-192FD HFCD-192FD-E | HFCE-075 HFCE-110 | HFCP-PTO | |||||
Power | ||||||||||
Power Type | Gasoline engine | Diesel engine | Diesel engine | Motor | PTO | |||||
Rated Power | 10.8 HP/8 Kw | 9.7 HP/7.2 Kw | 11 HP/8.2 Kw | 7.5 Kw /11 Kw | ||||||
Start Method | Electric/Rope | Electric/Rope | Electric/Rope | / | / | |||||
Oil type | 92# and below | 0# and below | 0# and below | Made to order | ||||||
Fuel tank capacity | 6 L | 5.5 L | 5.5 L | / | ||||||
Cutting tool | ||||||||||
Blade speed | 3600 r/min | 3600 r/mi | 3600 r/min | 2930 r/min | 3600 r/min | |||||
Blade length | 200 mm | 200 mm | 200 mm | 200 mm | 300 mm | |||||
Blade material | A8 tool steel | |||||||||
Size | ||||||||||
Overall size(mm) | 1400*800*1100 2400*900*1400 | 1400*800*1100 | 1400*800*1100 2400*900*1400 | 1400*800*1100 | 1400*800*1100 | |||||
Inlet height (mm) | 770-1100 | 770-1100 | 770-1100 | 770-1100 | floating | |||||
Inlet size (mm) | 800*700 | 800*700 | 800*700 | 800*700 | 800*700 | |||||
Height of discharge port (mm) | 870-1100 1130-1430 | 870-1100 | 870-1100 1130-1430 | 870-1100 | floating | |||||
Second discharge port | Yes/No | Yes | Yes/No | Yes | No | |||||
Total Weight | 165 kg 200 kg | 185 kg | 195 kg 220 kg | Made to order | 185kg | |||||
Performance | ||||||||||
Crushing efficiency | 1.5-2 t/h | 1-1.5 t/h | 1.5-2 t/h | 1-1.5 t/h 1.5-2 t/h | 2-3 t/h | |||||
Maximum diameter of broken branches | 80 mm | 80 mm | 80 mm | 80 mm | 120mm | |||||
Crushing effect | 10-20mm | |||||||||
Spraying distance | 1.5-2m | |||||||||
